With a flawless blend of smooth concrete and weathered stone, Windmere modernizes a traditional look to create a minimalist design.
Roll over image to zoom
Additional Colors
Available Shapes and Sizes
:
WI01
:
5/16
:
12X12, 18X18
:
Matte
:
V2: Medium
:
Mexico
:
WI01
:
3/8
:
12X24
:
Matte
:
V2: Medium
:
United States
:
WI01
:
1/4
:
2X2
:
Matte
:
V2: Medium
:
Mexico
Application
| Target Dcof Wet | Suitable | |
|---|---|---|
| Dry & Level - Interior Floor | N/A | ✔ |
| Wet & Level - Interior Floor | ≥0.42 | ✔ |
| Shower Floors (Residential or Light Commercial) | ≥0.42 | ✔ |
| Exterior Floor Applications (including pool decking & other wet areas with minimal footwear) | ≥0.60 | |
| Ramps & Inclines | ≥0.65 | |
| Walls/Backsplashes | N/A | ✔ |
| Countertops | N/A | ✔ |
| Pool Linings | N/A | ✔ |
| 3/16" | ||
|
● Manufacturer Advisory: All tile is measured by the DCOF AcuTestTM method. Tiles with DCOF values less than 0.42 are not recommended for use in areas with wet or slippery conditions. For more information, see ANSI standard A137.1 section 6.2.2.1.10, available at www.tileusa.com. ● A DCOF value of =0.42 is the standard for tiles specified for level interior spaces expected to be walked upon when wet, as stated in ANSI A137.1-A326.3. For more information about DCOF and the DCOF AcuTestTM, americanolean.com/DCOF. |
||
|
No additional notes |
||
Technical Specifications
| Test Method | Floor Tile | Mosaic Tile | |
|---|---|---|---|
| Water Absorption | ASTM C373 | < 7.0 | < 3.0 |
| Breaking Strength | ASTM C648 | > 250 lbs | > 250 lbs |
| Scratch Hardness | ASTM MOHS | 7 | 7 |
| Chemical Resistance | ASTM C650 | Resistant | Resistant |
Durability Chart
| Floor Surface Wear Resistance |
|---|
| 1 - Residential Bathrooms |
| 2 - All Residential Areas |
| 3 - All Residential / Light Commercial |
| 4 - All Residential / Commercial |
Available Trim (1)
Bullnose
3X12
Shape Number: P43C9
